Absolute Maximum AC Current Measurement:
600A ac
Absolute Maximum DC Current Measurement:
600A dc
Absolute Maximum AC Voltage Measurement:
600V ac
Absolute Maximum DC Voltage Measurement:
600V dc
Absolute Maximum Resistance Measurement:
60kΩ
Model Number:
AMP 220
Best DC Current Accuracy:
±(2% rdg + 5dgts)
Clamp Meter Type:
AC/DC Clamp Meter
Best AC Current Accuracy:
±(1.8% rdg + 5dgts)
Best AC Voltage Accuracy:
±(1% rdg + 5dgts)
Best DC Voltage Accuracy:
±(1% rdg + 5dgts)
True RMS:
Yes
Jaw Capacity Busbars:
35mm
Functions Measured:
AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
Dimensions:
224 x 77 x 37mm
Power Source:
Battery
Safety Category Voltage:
600V
Battery Type:
AAA
Safety Category:
CAT III 600V
Best Resistance Measurement Accuracy:
±1 % + 5LSD
Display Type:
LCD
Maximum Operating Temperature:
+40°C
Minimum Operating Temperature:
0°C
Height:
37mm
Maximum Conductor Size:
35mm
Weight:
254g
Safety Category Level:
CAT III
Non-Contact Voltage Detector:
Yes
Width:
77mm
Length:
224mm
